Swing Flood Barrier
Swing Flood Barrier
Model: SJ-SFB
Preview
Features
Tested by the German certification unit TUV PAS 1188 to achieve zero water leakage standards.
Spec
＊Product Specifications:
The door leaf is made of stainless steel with a thickness of 3.0mm, and a stainless steel square tube is used inside to strengthen the skeleton.
The movable back support is made of stainless steel flat tube 40*80*3.0mm, which can be stored directly behind the door leaf, without the need to disassemble the whole piece and store it separately, taking into account both beauty and practicality.
Using EPDM tape, it has high-density waterproof function, ozone resistance, sunlight resistance, aging resistance, steam resistance, high temperature resistance (120~130℃), good elasticity at low temperature, and good insulation is also a major feature. right
With regard to chemical resistance, it can easily cope with alkalis and polar solvents (such as alcohols, ketones), and can also tolerate many low concentrations of acids.
The U-shaped frame including the fixed bottom frame is made of stainless steel with a thickness of 6.0mm
The steel ball is used for positioning the pressing handle, and the positioning handle is shifted every 45 degrees (it can effectively avoid the inconvenience of operation and personal injury caused by the loosening or too tight of the general pressing rod)
＊Certification:
The material is stainless steel, which complies with the relevant regulations of CNS-8499G3164.
Compliant with PAS1188 waterproof standard test certificate
The door leaf is made of stainless steel with a thickness of 3.0mm, and a stainless steel square tube is used inside to strengthen the skeleton.
The movable back support is made of stainless steel flat tube 40*80*3.0mm, which can be stored directly behind the door leaf, without the need to disassemble the whole piece and store it separately, taking into account both beauty and practicality.
Using EPDM tape, it has high-density waterproof function, ozone resistance, sunlight resistance, aging resistance, steam resistance, high temperature resistance (120~130℃), good elasticity at low temperature, and good insulation is also a major feature. right
With regard to chemical resistance, it can easily cope with alkalis and polar solvents (such as alcohols, ketones), and can also tolerate many low concentrations of acids.
The U-shaped frame including the fixed bottom frame is made of stainless steel with a thickness of 6.0mm
The steel ball is used for positioning the pressing handle, and the positioning handle is shifted every 45 degrees (it can effectively avoid the inconvenience of operation and personal injury caused by the loosening or too tight of the general pressing rod)
＊Certification:
The material is stainless steel, which complies with the relevant regulations of CNS-8499G3164.
Compliant with PAS1188 waterproof standard test certificate
