Auto Flood Barrier Shutter
Auto Flood Barrier Shutter
Model: SJ-ASFB
Preview
Features
Breakthrough innovation, the door body has two practical designs of flood control and control, and the two functions can be freely switched through system settings.
Tested by the German certification unit TUV PAS 1188 to achieve zero water leakage standards.
Awards for Taiwan Excellence 2023.
Spec
＊Product Specifications:
The maximum use size is less than 5 meters in height and no more than 8 meters in width.
All iron parts are painted with powder paint with a thickness of more than 50um instead of liquid paint.
(It aims to strengthen the anti-rust treatment of iron parts and increase the service life; and when the subsequent recycling is melted down, no toxic gas will be generated due to high temperature)
＊Standard specification of door sheet: The door sheet is made of aluminum alloy aluminum extrusion, which is integrally formed and can withstand higher water pressure. The height of a single door panel is 340mm.
＊Track standard specifications: The material is iron, and the width of the rails on both sides is 250mm
＊The base material is stainless steel
＊The material of the rolling door box is iron
＊The upper (top) pressing mechanism of the door body and the inner pressing mechanism of the door rails on both sides have obtained patent certification in Taiwan, Japan and mainland China.
*The ratio of the sliding center column of the electric waterproof rolling door will be calculated according to the water pressure tolerance to achieve the waterproof function.
※The center column is designed to be operated in a convenient and labor-saving slide way, and it is also convenient for storage.
*Water level sensing setting, when the system detects that the water level reaches the set height, the system mechanism will automatically turn on the pressing function to quickly and effectively achieve the effect of flood control.
＊Certification:
The material is stainless steel, which complies with the relevant regulations of CNS-8499G3164.
And passed the most stringent zero leakage test.
The maximum use size is less than 5 meters in height and no more than 8 meters in width.
All iron parts are painted with powder paint with a thickness of more than 50um instead of liquid paint.
(It aims to strengthen the anti-rust treatment of iron parts and increase the service life; and when the subsequent recycling is melted down, no toxic gas will be generated due to high temperature)
＊Standard specification of door sheet: The door sheet is made of aluminum alloy aluminum extrusion, which is integrally formed and can withstand higher water pressure. The height of a single door panel is 340mm.
＊Track standard specifications: The material is iron, and the width of the rails on both sides is 250mm
＊The base material is stainless steel
＊The material of the rolling door box is iron
＊The upper (top) pressing mechanism of the door body and the inner pressing mechanism of the door rails on both sides have obtained patent certification in Taiwan, Japan and mainland China.
*The ratio of the sliding center column of the electric waterproof rolling door will be calculated according to the water pressure tolerance to achieve the waterproof function.
※The center column is designed to be operated in a convenient and labor-saving slide way, and it is also convenient for storage.
*Water level sensing setting, when the system detects that the water level reaches the set height, the system mechanism will automatically turn on the pressing function to quickly and effectively achieve the effect of flood control.
＊Certification:
The material is stainless steel, which complies with the relevant regulations of CNS-8499G3164.
And passed the most stringent zero leakage test.
